1. Power Information

• Power range: 220 - 240 V AC 50Hz
• Power: 1700 - 2030 W
• Motor: 12 V DC
• Fan Voltage: 12 V DC

2.Product Dimensions and Weight Information

• Length: 600mm
• Width: 380mm
• Height: 568mm
• Seat Height: 530mm
• Exhaust Port Center Height: 400mm
• Air Intake Center & Ash Removal Port Height: 220mm
• Unit Weight: 35KG
• Ash Pan Capacity: 5L

• The Incineration Toilet x 1
• Instruction Manual x 1
• Bowl Liner ( 500 pcs / box ) x 1
• The Installation Kits

There are three types of installation kits, please consult sales customer service when purchasing the product to choose the most suitable kit based your installation environment.

1. Standard Vertical Hard Pipe Kit

• 304 Stainless Steel Rain Cap x 1
• Smooth Sweep Tee x 1
• 110mm Exhaust Pipe 1m x 2
• 304 Stainless Steel Side Exhaust/Intake Guard x 1
• 304 Stainless Steel Clamp Adjustable 100-150mm x 2
• M4 / 12mm Countersunk Self-tapping Screw (304 Stainless Steel) x 12

2. Standard Vertical Flexible Hose Kits

• 304 Stainless Steel Rain Cap x 1
• 110mm Extendable Flexible Hose x 1
• 304 Stainless Steel Side Exhaust/Intake Guard x 1
• 304 Stainless Steel Clamp Adjustable 100-150mm x 1
• M4 / 12mm Countersunk Self-tapping Screw (304 Stainless Steel) x 12
• 110mm Exhaust Hard Pipe 20cm x 1

3. Side Installation Hard Pipe Kit

• 110mm Exhaust Pipe 30cm x 1
• 110mm Exhaust Pipe 60cm x 1
• 304 Stainless Steel Side Exhaust/Intake Guard x 1
• M4 / 12mm Countersunk Self-tapping Screw (304 Stainless Steel) x 10
